Product Technical Details
The Heating oven is specially used for both motor & transformer industries. By heating technique, the moisture is evaporated from the copper coiling and improves the electrical parameters.
The Heating Oven is fabricated out of a 2 mm MS sheet outside and a 2 mm SS sheet inside. 250 mm square tubes are used to fabricate the skeleton of the oven.
The front door provided is a double door with a Single locking arrangement. Door Opening will be more than 130 ͦ.
The Oven is Insulated with 98-density rook wool 250 mm thick.
A motorized trolley of 15ton capacity is provided for this oven. The trolley consists of a total of 6 wheels out of which 2 are provided with gear teeth which in turn are coupled with the motored gearbox. The suitable capacity of the railing is provided for easy movement of the trolley.
A total of 96 heaters are provided which are mounted on both internal side walls of the oven. The heaters are divided into 8 groups.
Ducting is provided on the inside for internal air circulation. Numerous doors are provided to the ducting to allow access for heater maintenance.
4 quantity of blowers is mounted on top of the oven for internal air circulation.
Exhaust is provided on top of the oven.
![Heating-Oven](https://unitedetpl.com/wp-content/uploads/2021/03/Heating-Oven.png)
![ELECTRICAL HEATING OVEN-1](https://unitedetpl.com/wp-content/uploads/2021/03/ELECTRICAL-HEATING-OVEN-1-225x300.jpg)
![](https://unitedetpl.com/wp-content/uploads/2021/03/ELECTRICAL-HEATING-OVEN-2-225x300.jpg)
![](https://unitedetpl.com/wp-content/uploads/2021/03/Heating-Oven-2-300x175.png)
